SMD SPI Tape Light: Tuneable White

SPI-Controlled Tunable White SMD LED Tape

UL Listed · Manufactured by LUXX since 1996 · Backed by a 3-year warranty, extendable to 5. Request a project quote.

An ultra-slim LED tape light for flexible, custom installations across retail and architectural environments.

Cuttable to length and shape, it adapts easily to a wide range of applications. SPI controlled for precise, addressable lighting effects and transitions.

  • SPI Control

    SPI-driven protocol means fast, flicker-free lighting at your command.

  • 12V Voltage

    Supports standard cascading up to 5 meters per run with consistent illumination throughout.

  • Flexible FPC Design

    High-thermal-conductivity flexible circuit board, allowing free bending for easy routing and installation in complex profiles.

  • IP20 & IP65 available

    IP20 for interiors, IP65 for outdoors. Light with confidence in any environment

Specifications

Model SMD-0108TW80-12-301   (IP20)

SMD-0108TW80-12-311   (IP65)
Input Voltage DC 12V
Dimensions (W x H) IP20: 0.315 x 0.08 inch (8 × 2.1 mm)

IP65: 0.39 x 0.157 inch (10 × 4 mm)
Power Per Color 2.62 W/ft (8.6 W/m)
Light Output 2100K: 171 lm/ft (560 lm/m)
6500K: 223 lm/ft(730 lm/m)
LED Qty ~33 / ft (108 / m
Protocol SPI (WS2811)
Pixel ~11 pixels / ft (36 pixels / m)
Color Temperature 2100K, 6500K
Min. Cut Length 1.09” (27.78 mm)
Max. Cascade Length 16.4 ft (5 m)
PCB Material Double-sided FPC
Lead Wire (20 AWG leads, both ends) 5.9” (150 mm)
IP Rating IP20
Mounting 3M Tape
Energy Efficiency Index (EEI) G or Exempt (Module size 27.78mm)
CRI (Ra) > 80

SMD SPI Tape Light Tuneable White-drawing
