Single Color COB LED Tape Light

A 8mm-wide single color COB tape light with 480-chips per meter operating at DC 24V.

UL Listed · Manufactured by LUXX since 1996 · Backed by a 3-year warranty, extendable to 5. Request a project quote.

Description

An ultra-slim single-colour COB tape light delivering smooth, uniform illumination for retail and architectural applications.

Operating at 24V DC, it offers consistent light quality and flexible installation across shelving, displays, and interior environments where precision and clean visual output matter.

SPI Control

SPI-driven protocol means fast, flicker-free lighting at your command.
DC 24V Voltage

Supports standard cascading up to 5 meters per run with consistent illumination throughout.
Flexible PCB Design

High-thermal-conductivity flexible circuit board, allowing free bending for easy routing and installation in complex profiles.
180° Beam Angle

LED chips mounted directly on FPC achieve a full 180° emission angle, maximizing light distribution and surface wash efficiency.
High-Tack Thermal Adhesive

Pre-applied, high-adhesion, thermally conductive

double-sided tape on the back ensures fast and durable installation on any clean surface.

Specifications

Model	COB-0480XX90-24-0401
Input Voltage	DC 24V
Dimensions (W x H)	0.315 x 0.08” (8 × 2 mm)
Power	3.35 W/ft (11 W/m)
Light Output	2700K: 303 lm/ft (994 lm/m) 3000K : 328 lm/ft (1077 lm/m) 4000K: 348 lm/ft (1141 lm/m) 6500K: 349 lm/ft (1147 lm/m)
LED Qty	~146 / ft (480 /m)
Min. Cut Length	1.97” (50 mm)
Max. Cascade Length	16.4 ft (5 m)
PCB Material	Double-sided FPC
Lead Wire (20 AWG leads, both ends)	5.9” (150 mm)
Mounting	3M Tape
Energy Efficiency Index (EEI)	Class G (Module size 50mm)
