SPI-Controlled Single-Colour COB LED Tape, 10mm

UL Listed · Manufactured by LUXX since 1996 · Backed by a 3-year warranty, extendable to 5. Request a project quote.

A 10mm single-colour COB tape light delivering smooth, uniform illumination with a clean, dot-free appearance.

Designed for retail and architectural applications, it integrates easily into displays and interior features. SPI-driven protocol means fast, flicker-free, and individually addressable lighting at your command

  • SPI Control

    SPI-driven protocol means fast, flicker-free lighting at your command.

  • 24V Voltage

    Supports standard cascading up to 5 meters per run with consistent illumination throughout.

  • Flexible FPC Design

    High-thermal-conductivity flexible circuit board, allowing free bending for easy routing and installation in complex profiles.

  • IP20 & IP65 available

    IP20 for interiors, IP65 for outdoors. Light with confidence in any environment

Specifications

Model COB-0360XX90-24-1301 (IP20)

COB-0360XX90-24-1311 (IP65)
Input Voltage DC 24V
Dimensions (W x H) IP20: 0.39 x 0.09” (10 × 2.3 mm) IP65: 0.47 x 0.157” (12 × 4 mm)
Power 0.82 W/ft (2.7 W/m)
Light Output 2700K: 243.8 lm/ft (800 lm/m) 3000K: 243.8 lm/ft (800 lm/m) 4000K: 274.3 lm/ft (900 lm/m) 6500K: 304.8 lm/ft (1000 lm/m)
CRI (Ra) > 90
Protocol SPI (WS2811)
Pixel ~3.66 pixels / ft (12 pixels / m)
Min. Cut Length 3.28” (83.33 mm)
Max. Cascade Length 16.4 ft (5 m)
PCB Material Double-sided FPC
Lead Wire (20 AWG leads, both ends) 5.9” (150 mm)
Mounting 3M Tape
Energy Efficiency Index (EEI) Class G (Module size 83.33mm)

drawing ip20 + IP65
