Monza Linear

Monza Linear

PMMA LED shelf lighting fixture with a linear effect similar to that of fluorescent tubes

UL Listed · Manufactured by LUXX since 1996 · Backed by a 3-year warranty, extendable to 5. Request a project quote.

A special optical diffuser makes the LED dots invisible, creating a linear effect similar to that of fluorescent tubes.

Different configurations available upon request.

Electrical
Power 9.6 W
Input Voltage 12 VDC / 24 VDC
Current 400 mA / 800 mA
LED
Strip maximum width 0.31 in (8 mm)
Type 3020
Qty 120 pcs
CCT 2700K / 3000K / 4000K / 5000K / 6000K
CRI  > 80
Light Output

Beam angle

 120°
Efficiency  60 Lm/W
Lumen 576 Lm
Dimmability
Dimmable
Appearance
Material anodized aluminum, PMMA
Diffuser milky
Dimensions W0.43 in (11 mm) x H0.55 in (14 mm)

Max. length available

 98.43 in (2500 mm)
Mounting
Surface
Accessories
Spring steel clips
Wire Exit
Linear
LED lighting fixture Monza Linear drawings, including dimensions, mounting options (magnetic clip, screw, adhesive tape)
