LIGHTPANEL One Single Color

LED light guide panels in single color, as slim as 3mm

UL Listed · Manufactured by LUXX since 1996 · Backed by a 5-year warranty. Request a project quote.

Description

Our LUXX LIGHTPANEL offers bright, even backlighting with uniform illumination across the panel’s surface. As slim as 3mm, LIGHTPANEL is the perfect choice for tight spaces.

LIGHTPANEL’s light transmission and durability are exemplary due to our PMMA acrylic sheets that boast 96% optical clarity. The sheets are laser-dotted to optimize light distribution and create a sleek, seamless finish. Top it with our optional special-grade thin diffusion film to eliminate LED hot spots, ensuring uniform brightness without compromising light projection or overall illumination.

With LIGHTPANEL, light is crisp and bright with a high CRI. It’s the perfect choice for retail, architectural, custom, OEM and industrial projects.

LEDs on one side

Ideal for LED Light Panels under 14” (355mm), Ensures a well-lit light guide panel that is not over-bright while eliminating the slight drop associated with larger panels.

LEDs on two sides

For LED Light Panel larger than 14 “ (355mm), we recommend adding a LED strip to two opposing sides of the light guide panel.

LEDs on four sides

For LED Light Panels larger than 36 “ (914mm) or LGPs that are square or near square in shape, we commend adding LEDs to all four sides.

Options

Manufacturing Technology	Laser machine for precise cutting of panel and laser engraving for fully optimized dot diffusion pattern
PMMA Panel Thickness	0.118” – 0.394” (3mm – 10mm)
Mounting	No mounting accessories or hardware included
Application	Indoor (IP Protected version available upon request)
Overall Finish	J-Chanel, Crystal or Taped
Light Entry	1-sided, 2-sided, 3-sided, or 4-sided
Diffusion Film or Diffusion Panel	Optional
Panel AIR Shield (Reflection Sheet)	Optional, thickness 0.010” – 0.016” (0.25mm – 0.4mm)
Taped	Optional
Power Exist	Custom defined, bottom left, bottom right, upper left, upper right, bottom middle, upper middle
Power Exit Connecting Cable	6” White Male IP54 Connecting Cable or Barrel Plug (customer define)

Color Temperature	CRI	LEDs/Ft	Lumens/Ft	Power Consumption
3000K	90	73 LEDs/ft	450	5.5W/ft
4000K	90	73 LEDs/ft	465	5.5W/ft
5000K	90	73 LEDs/ft	468	5.5W/ft
6500K	90	73 LEDs/ft	478	5.5W/ft

Power
Input Voltage	24V DC
Power Supply	Optional, 24V DC power supply not included, can be purchased separately
Wire Output Connector	Optional, 40’’ White Female IP54 Connector or 5.5×2.1 mm DC barrel plug
Operating Temperature	-20°C~+40°C

Installation
Mounting	No mounting accessories or hardware included
LEDs & Panel	24 months
Certification	UL

Light Guide Panels for Every Need

LUXX LED Light Panels are customizable to suit virtually any specification. Our Light guide panels (LGP) come in any size shape, color. Our materials meets strict safety requirements. And our light panels offer the customizability to make any backlighting vision come to life.
