LIGHTPANEL Vizzion Slim

An ultra-slim LED light panel with an optional mounting rail

Description

The LIGHTPANEL Vizzion Slim LED Light Panel combines elegant lighting with practical design. Featuring an optional integrated mounting rail and ultra-thin profile, it ensures quick and seamless setup. With its clean, slim, modern aesthetic and uniform, high-quality illumination, it’s ideal for retail, architectural, custom, and industrial applications. The built-in system guarantees effortless installation and reliable, long-lasting performance.

Lasting: Features J-Channel thermal management and integrated heat sink for maximum longevity.
High quality: Tier 1 ANSI Binned LED strips
Ultra thin: Our slimmest Vizzion, perfect for spaces with limited depth
Custom-made at our advanced USA facility

Specifications

Manufacturing Technology	PMMA optical grade cell cast acrylic, laser cut & engraved for optimized dot diffusion
PMMA Panel Thickness	0.134” (3.4mm)
Size	Customizable size with maximum size to 74”x48” (1880 x 1219mm)
Application	Indoor (IP Protected version available upon request)
LED Light Entry	2-sided LED strips
Panel Vizzion Shield	Thin reflective sheet for additional brightness and even light distribution
Taped	Sides taped with durable UV & solvent resistant metalized polyester film
Finish	Double Channel J profile with integrated heat sink technology for reliable thermal management, framed four sides
Connecting Cable	6” White Male IP54 Connecting Cable/ DC barrel connector

Lighting

Color Temperature	1800K-6500K
LEDs	3020 SMD,160LED/m

Electrical

Power	5.5W/ft,24V DC Power Supply with AC cord and DC white Female IP54 Cord/DC barrel
Operating Temperature	20°C~+40°C

Installation

Installation	Mounting rail available upon request

Warranty and Certifications

LEDs & Panel	24 Months

Light Guide Panels for Every Need

LUXX LED Light Panels are customizable to suit virtually any specification. Our Light guide panels (LGP) come in any size shape, color. Our materials meets strict safety requirements. And our light panels offer the customizability to make any backlighting vision come to life.
