Milano

Aluminum LED cooler lighting fixture

Milano is dedicated to wall type vertical freezers & chillers.

The special lens design creates an even light distribution up to 20 in (500 mm) to both sides.

Meat display version also available.

Different configurations available upon request.

SPECIFICATIONS

Data per inch (meter)

Electrical

Power: 20 W

Input voltage: 24 VDC

Current: 833 mA

LED

Type: 3535

Qty: 19 pcs

CCT: 2700 K – 3000 K

CRI > 80

Light Output

Beam angle: re-directed 180°

Efficiency: 78 Lm/W

Lumen: 1560 Lm

Dimmability

Dimmable

Working temperature

-13°F (-25°C) / -31°F (-35°C) to +113°F (45°C)

Appearance

Dimensions: L39.37 in (1000 mm) x W1.77 in (45 mm) x H0.9 in (22.8 mm)

Max. length available: 98.43 in (2500 mm)

Diffuser: clear

Mounting

Screws / magnets

Wire Exit

Linear & 90° x 3 ways out
