LXT8-M
SPECIFICATIONS
Lengths
23.62 in (600 mm) / 35.43 in (900 mm) / 47.24 in (1200 mm) /
59.06 (1500 mm) / 70.87 (1800 mm)
Electrical
Power: 10 W / 14 W / 18 W /
23 W / 29 W
Input voltage: 100 – 240 VAC
Power factor > 0.95
LED
Type: 3020
Qty: 144 pcs / 216 pcs / 300 pcs /
372 pcs / 444 pcs
CCT: pink
CRI > 80
Light Output
Beam angle: 120°
Efficiency: 100 Lm/W
Lumen: 1056 Lm / 1349 Lm
Dimmability
NON Dimmable
Working temperature
-13°F (-25°C) to +113°F (45°C)
Appearance
Material: aluminum, PC
Diffuser: clear
Base: G13 – 180° rotatable
Diameter: ø 1.02 in (26 mm)
Double isolated, single side ended tube
LXT8-B
SPECIFICATIONS
Lengths
23.62 in (600 mm) / 35.43 in (900 mm) / 47.42 in (1200 mm) /
59.06 in (1500 mm) / 70.87 in (1800 mm)
Electrical
Power: 10 W / 14 W / 18 W /
23 W / 29 W
Input voltage: 100 – 240 VAC
Power factor > 0.95
LED
Type: 3020
Qty: 144 pcs / 216 pcs / 300 pcs /
372 pcs / 444 pcs
CCT: amber + 2700K
CRI > 80
Light Output
Beam angle: 120°
Efficiency: 74 Lm/W
Lumen: 1056 Lm / 1349 Lm
Dimmability
NON Dimmable
Working temperature
-13°F (-25°C) to +113°F (45°C)
Appearance
Material: aluminum, PC
Diffuser: clear
Base: G13 – 180° rotatable
Diameter: ø 1.02 in (26 mm)
Double isolated, single side ended tube
LXT8-C
SPECIFICATIONS
Lengths
47.42 in (1200 mm) / 59.06 in
(1500 mm)
Electrical
Power: 18 W / 23 W
Input voltage: 100 – 240 VAC
Power factor > 0.9
LED
Type: 3014 + 3528
Qty: 300 pcs / 372 pcs
CCT: amber + 3000 K
CRI > 80
Light Output
Beam angle: 120°
Efficiency: 63 Lm/W
Lumen: 826 Lm / 1406 Lm
Dimmability
NON Dimmable
Working temperature
-13°F (-25°C) to +113°F (45°C)
Appearance
Material: aluminum, PC
Diffuser: clear
Base: G13 – 180° rotatable
Diameter: ø 1.02 in (26 mm)
Double isolated, single side ended tube
LXT8-V
SPECIFICATIONS
Lengths
47.42 in (1200 mm) / 59.06 in (1500 mm)
Electrical
Power: 18 W / 23 W
Input voltage: 100 – 240 VAC
Power factor > 0.9
LED
Type: 3020
Q‘ty: 300 pcs / 372 pcs
CCT: 3000 K
CRI > 90 / CRI > 95
Light Output
Beam angle: 120°
Efficiency: 63 Lm/W
Lumen: 826 Lm / 1406 Lm
Dimmability
NON Dimmable
Working temperature
-13°F (-25°C) to +113°F (45°C)
Appearance
Material: aluminum, PC
Diffuser: clear
Base: G13 – 180° rotatable
Diameter: ø 1.02 in (26 mm)
Double isolated, single side ended tube
APPLICATIONS
